Greatfold Safety Demountable Classroom Sliding Door Partition Wall
-
10 - 99 Square Meters
$108.00
-
>=100 Square Meters
$90.00
- Color:
-
- Shipping:
- Support Sea freight · Land freight · Air freight
- Lead Time:
-
Quantity(Square Meters) 1 - 200 201 - 500 >500 Est. Time(days) 15 25 Negotiable
- Customization:
-
Customized logo (Min. Order: 10 Square Meters)Graphic customization (Min. Order: 10 Square Meters)
More
Customized packaging (Min. Order: 10 Square Meters) Less
- Samples:
- Type:
-
Office Furniture
- General Use:
-
Commercial Furniture
- Place of Origin:
-
Guangdong, China
- Brand Name:
-
GreatFold
- Model Number:
-
GLS-85A18 partition wall
- Thickness:
-
85 mm, customize available.
- Width:
-
680-1228 mm
- Heigth:
-
2000-6000 mm
- Contract Range:
-
22.5 mm
- Sound insulation coefficient:
-
32-45 dB
- Surface Material:
-
Laminate panel, Melamine panel, Hard fabric,Soft fabric etc
- Frame Material:
-
6063-T6 Aluminum Alloy
- Weight:
-
28-38 KG
- Pass door selection:
-
Single or double door
- Function:
-
Soundproof Partition Wall Panels
- Supply Ability:
- 30000 Square Meter/Square Meters per Year
- Packaging Details
- Carton package,MDF batten on four section sides,foam board on both front face.
Paper board or plywood case,up to customer's requirement.
- Port
- GUANGZHOU,CHINA
- Picture Example:
-
- Lead Time :
-
Quantity(Square Meters) 1 - 200 201 - 500 >500 Est. Time(days) 15 25 To be negotiated
Greatfold Safety Demountable Classroom Sliding Door Partition Wall
Types of Partition :
Our GreatFold movable partitions are classified according to their Thickness,
Height & Sound Proofing Coefficient.Our “Type” Signifies the Thickness of
Partition in “MM”
- GLS-65 Economic Partition
- GLS-85 Standard Partition
- GLS-100 Deluxe Partition
- GLS-H Ultra High Partition
Glass Movable Partition:
- GLS-G40 Framelee Operable Glass Wall
- GLS-G65/85 Full Frame Movable Glass Wall
GreatFold Partition finishes palette is available on request.(The movable partition
surface can also be customized according to your needs, such as double-sided
color, landscape painting and various patterns.)
Surface Material : MDF / Acoustic MDF Panel / Melamine board /
Hard Fabric / Sorf Fabric(Leather / Pleather / Melange Fabric)
How to select the suitable movable wall for your site?
We have 5 types of movable wall , 65type , 80type , 100type and 125 ultra-high type . You can choose the right
movable wall upon the Height and Soundproof requirement as following,
65 type— Max height 3.5m, soundproof: 38dB to 43dB
80 type— Max height:5.5m,Soundproof: 43dB to 53dB
85 type— Max height:5.5m,Soundproof: 43dB to 53dB
100 type— Max height:7m,Soundproof: 43dB to 58dB
125ultra-height — Max height:17m,Soundproof : 38dB to 48dB
What you should do on site ?
A beam(truss) should built on site for track installation . The min distance leaving for track installation from false
ceiling to top ceiling is 200mm .
How to install ?
We will provide the installation manual and video guiding the installation job . We can also dispatch the installation
engineer supervising the installation as request .
What is lead time ?
The lead time is 7 days to 10 days .
How to transport ?
Sea transport is a common mode of transportation. In an emergency, can be air freight.
How do the goods packing ?
Corrugating paper packaging, MDF batten cover all around corner .
The movable wall panel and track, fittings will be packed separately .
What is Procurement procedure ?
Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling
to finished floor and width from wall to wall)
Secondly , we offer you the movable wall layout drawings for your confirmation
Thirdly , we quote the movable wall in accordance with confirmed drawings .
